Aaeon BOXER-6614 - Battery (CN31)

Embedded Controller
B O X E R - 6614
Chapter 2 Hardware Installation 2 - 36
2.35 Battery (CN31)
Pin
Pin Name
Signal Type
Signal Level
1
+3.3V
PWR
3.3V
2
GND
GND
2.36 CFast Slot (CN33)
Pin
Pin Name
Signal Type
Signal Level
S1
GND
GND
S2
SATA_TX+
DIFF
S3
SATA_TX-
DIFF
S4
GND
GND
S5
SATA_RX-
DIFF
S6
SATA_RX+
DIFF
S7
GND
GND
PC1
NC
PC2
GND
GND
PC3
NC
PC4
NC
PC5
NC
PC6
NC
PC7
GND
GND
PC8
NC
PC9
NC
PC10
NC
