Aaeon BOXER-6614 - DDR3 L SO-DIMM Slot (CN34)

Embedded Controller
B O X E R - 6614
Chapter 2 Hardware Installation
2 - 37
PC11
NC
PC12
NC
PC13
+3.3V
PWR
+3.3V
PC14
+3.3V
PWR
+3.3V
PC15
GND
GND
PC16
GND
GND
PC17
NC
2.37 DDR3L SO-DIMM Slot (CN34)
Standard specification
2.38 UIM Card Socket (CN35)
Pin
Pin Name
Signal Type
Signal Level
1
UIM_PWR
PWR
2
UIM_RST
IN
3
UIM_CLK
IN
4
GND
GND
5
UIM_VPP
PWR
6
UIM_DATA
I/O
2.39 Mini-Card Slot (Full-Mini Card) (CN37)
Pin
Pin Name
Signal Type
Signal Level
1
PCIE_WAKE#
IN
2
+3.3VSB
PWR
+3.3V
