Embedded Controller BOXER- 6614
IO=2E8h;
IRQ=3,4,5,6,7,9,10,11,12;
IO=3E8h;
IRQ=3,4,5,6,7,9,10,11,12;
IO=2E8h;
IRQ=3,4,5,6,7,9,10,11,12;
Working model RS232 Default
RS422
RS485
Select Working model
Change Settings
(Serial Port 4)
Auto Default
IO=2E8h; IRQ=7;
IO=3F8h;
IRQ=3,4,5,6,7,9,10,11,12;
IO=2F8h;
IRQ=3,4,5,6,7,9,10,11,12;
IO=3E8h;
IRQ=3,4,5,6,7,9,10,11,12;
IO=2E8h;
IRQ=3,4,5,6,7,9,10,11,12;
Allows BIOS to Select Serial Port resource.
Smart Fan Function Enable
Disable Optimal Default, Failsafe Default
Chapter 3 Award BIOS Setup 3-15
