Chapter 2 – Hardware Information 11
Fanless Embedded Box PC BOXER-6639
2.4 List of Connectors
Please refer to the table below for all of the system’s connectors that you can configure
for your application
Label
Function
VGA
DB-15 CRT port
DC-IN
9~36V DC-IN connector
HDMI1
HDMI connector
HDMI2
HDMI connector
DIO
8- bit Digital Input & Output connector
USB 3.0 Port 1~4
USB 3.0 Port
USB 2.0 Port 1~2
USB 2.0 Port
LAN Port 1~3
RJ45 10/100/1000MBps LAN connector
Audio Jack
3.5mm Audio Line-out connector
Remote Power Button
2-pin Remote power on/off button
CFast
CFast slot connector
Power Switch
Power on/off switch
Reset Switch
H/W Reset switch
SATA Power Connector 1~2
SATA Storage power connector
SATA Signal Connector 1~2
SATA Storage signal connector
COM 1/2/3/4/5/6
DB9 RS232/422/485 connector
MiniCard 1~2
PCI Express Minicard slot
SIM Slot
SIM card connector
DDR4 SODIMM Slot 1~2
DDR4 260-pin memory bank
