Aaeon BOXER-6639 - VGA Port; DC-In; HDMI Port (HDMI1;HDMI2)

Chapter 2 – Hardware Information 12
Fanless Embedded Box PC BOXER-6639
2.4.1 VGA Port
Pin
Signal
Pin
Signal
1
Red
2
Green
3
Blue
4
NC
5
GND
6
GND
7
GND
8
GND
9
VGA_VCC
10
GND
11
NC
12
DDC_DATA
13
VGA_HSYNC
14
VGA_VSYNC
15
DDC_CLK
2.4.2 DC-IN
Pin
Signal
Pin
Signal
1
PWR_IN
2
GND
3
NC
2.4.3 HDMI Port (HDMI1/HDMI2)
Pin
Signal
Pin
Signal
1
HDMI_DATA2_P
2
GND
3
HDMI_DATA2_N
4
HDMI_DATA1_P
5
GND
6
HDMI_DATA1_N
7
HDMI_DATA0_P
8
GND
9
HDMI_DATA0_N
10
HDMI_CLK_P
