Aaeon BOXER-6639 - Remote Power Button; Cfast

Chapter 2 – Hardware Information 15
Fanless Embedded Box PC BOXER-6639
Pin
Signal
Pin
Signal
U2
(A)D-
U11
(B)D-
U3
(A)D+
U12
(B)D+
U4
GND
U13
GND
U5
(A)SSRX-
U14
(B)SSRX-
U6
(A)SSRX+
U15
(B)SSRX+
U7
GND
U16
GND
U8
(A)SSTX-
U17
(B)SSTX-
U9
(A)SSTX+
U18
(B)SSTX+
2.4.6 Remote Power Button
Pin
Signal
Pin
Signal
1
PANSWH#
2
GND
2.4.7 CFast
Pin
Signal
Pin
Signal
S1
GND
S2
TX+
S3
TX-
S4
GND
S5
RX-
S6
RX+
S7
GND
P1
CD
P2
GND
P3
NC
P4
NC
P5
NC
P6
NC
P7
GND
P8
NC
P9
NC
P10
NC
