Aaeon BOXER-6639 - Page 31

Chapter 2 – Hardware Information 18
Fanless Embedded Box PC BOXER-6639
17
NC
18
GND
19
NC
20
W_DISABLE#
21
GND
22
PCIE_RST#
23
PCIE_RX-
24
+V3.3A
25
PCIE_RX+
26
GND
27
GND
28
+1.5V
29
GND
30
SMB_CLK
31
PCIE_TX-
32
SMB_DATA
33
PCIE_TX+
34
GND
35
GND
36
USB_D-
37
GND
38
USB_D+
39
+V3.3A
40
GND
41
+V3.3A
42
NC
43
GND
44
NC
45
NC
46
NC
47
NC
48
+1.5V
49
NC
50
GND
51
NC
52
+V3.3A
