100
COMMAND
NAME
DESCRIPTION No.
COMMAND SYNTAX
Command Argument 1 Argument 2 Argument 3 Argument 4 Response
Signal Conditioner Settings
Sets/Reads instrument Signal Conditioner Parameters Note: the signal conditioner parameters were set on the factory to keep best performance. Do not change Signal Conditioner parameters unless instructed by factory technical representative! NOTE: NLES parameter a1 must be more than a0. Similar NLES parameter D1 must be more than D0.
23 SC
M Read/Change Device Flow Signal Conditioner NLES mode E – Enabled* D – Disabled (No Conditioning)
<New Mode> [E/D]
SCM:<value> Example: SCM:E
No Argument (Returns current Mode)
SCM:<value> Example: SCM:E
R Flow Running Average Damping [1-255] 1-Disabled*
<new value> [1-255]
SCR:<value> Example: SCR:1
No Argument (Returns current
SCR:<value> Example: SCR:1
A AP Sensor Compensated signal conditioning NILES A0 and A1 parameters (do not change factory default setting unless instructed by tech support).
<a0_valve> [0.01- 0.99]
<a1_value> [0.01- 0.99]
Example: SCA:0.20,0.80
No Argument (Returns Current settings values)
F AP Sensor Running Average Damping [1-255] samples 1-Disabled*
<new value> [1-255]
SCF:<value>Example: SCF:4
No Argument (Returns) Current settings value
SCF:<value> Example: SCF:4
P Read/Change Device AP Signal Conditioner NLES mode E-Enabled* D-Disabled
No Argument (Returns Current settings value)
Example: SCP:E
<New Mode> [E/D]
Example: SCP:E
D AP Sensor Compensated signal conditioning NILES D0 and D1 parameters (do not change factory default settings unless instructed by tech support).
<D0_value> [0.01- 0.99]
<D1_value> [0.01- 0.99]
SCD:<value> Example: SCD:0.20.0.80
No Argument (Returns Current settings values)
SCD:<value> Example: SCD:0.20,0.80
T Temp Running Average Damping [1-255] 1-Disabled
<new value> [1-255]
SCT:<value>Example: SCT:10
No Argument (Returns current setting value)
SCT:<value> Example: SCT:10
