101
COMMAND
NAME
DESCRIPTION No.
COMMAND SYNTAX
Command Argument 1 Argument 2 Argument 3 Argument 4 Response
OLED and Process Screens Settings**
Sets/Reads OLED related parameters**. Argument 1 = S Process Screens Mask register: 0x00FF – screen mask (8 bits wide). Set bit – Enable Screen Clear bit – Disable Screen See the list of Process Screens below: 0x01 – M Flow Rate / Set Point 0x02 – M Flow Rate / Totalizer#1 0x04 – M Flow Rate / Totalizer#2 0x08 – M Flow Rate / V Flow Rate 0x10 – Confi guration Info 0x40 – PSP Status Info 0x80 – Instr. Troubleshooting NOTE: Screen #1 (0x01) cannot be disabled. "L" command without any argument will return OLED status: Y– Display Installed N– Display not installed When Argument #2 is not submitted command returns current settings.
24 L
M LCD Process Screen Mode: S - Static D - Dynamic
<New Value> S or D
LM:<value> Example: LM:S
No Argument (Returns Current Settings)
LM:<value> Example: LM:S
C OLED Screen Saver Brightness Level: [1-128]
<new value> [1-128]
LC:<value> Example: LC:6
No Argument LC:<value> Example: LC:6
B OLED operational Brightness Level: [1-255]
<new value> [1-255]
LB:<value> Example: LB:127
No Argument LB:<value>
Example: LB:127
O OLED Screen Saver Time Delay before activation: [1-36000] seconds
<new value> [1-36000]
LO:<value> Example: LO:900
No Argument LO:<value>
Example: LO:900
P OLED Screen Saver Mode 0 – Screen Saver Disabled 1 – Low Brightness mode 2 – Vertical Scrolling mode 3 – OLED off
<new mode> [0 - 3]
LP:<value> Example: LP:2
No Argument (Returns Current settings)
LP:<value> Example: LP:2
T OLED Screen Saver Time interval in sec. (for dynamic mode)
<New Value>[1-3600] LT:<value>
ExampleLT:5
No Argument LT:<value> Example:T:5
S OLED Process Screens Mask register
No Argument (Returns Current Settings)
Example: LS:0x3 (only fi rst two screens are enabled 0x01 and 0x02)
<Valve> 0x0001–0x003F (all 6 characters are required)
Example:LS:0x3F (all six screens are enabled)
D OLED Flow Reading decimal point precision: 0 - Normal 1 – Elevated (+1)
<new value> [0-1]
LD:<value> ExampleLD:1
No Argument (Returns Current settings)
LD:<value> ExampleLD:1
