Print Format
Item
Parameter Description
x 0 No print 00 : Line feed only
x 1 Device number ID# Selected at f06
x 2 Code memory number CD:x
x 3 Data number No.xxxxx
x 4 Judged result HH/H/OK/L/LL (2 digits)
x 5 Date 11/11/11 YMD order selected at f51
x 6 Time hh:mm:ss (AM or PM)
x 7 Accumulated data
x a
Displayed value
G or N xxxx uu
Effective only with 0a,4a
x b Gross weight G xxxx uu Effective only with 0b,4b
x C Net weight N xxxx uu Effective only with 0c,4c
x d Tare Weight Effective only with 0d,4d
0 x No print
1 x Device number ID# Not effective with 1a – 1d
2 x Code memory number CD:x Not effective with 2a – 2d
3 x Data number No.xxxxx Not effective with 3a – 3d
4 x Judged result HH/H/OK/L/LL (2 digits)
5 x Date 11/11/11
Effective only with
50 to 54 and 56
6 x Time hh:mm:ss (AM or PM) Effective only with 60 to 64
7 0
Accumulated data Total xxxx uu (2 lines)
8 0
Accumulation count xxx
9 1
+
9 2
-
9 3
*
9 4
/
9 5
=
9 6
.
9 7
#
Print specified letters in
one line (16 digits).
f70 [Type3]
Print Format 1
Initial setting
E1 0A
f71 [Type3]
Print format 2
Initial setting
1 80, E2 70
10
2
=Printing order
select using the ZERO
key
10
1
=Left side
10
0
=Right side
select using the 0 -
9 , A - F keys
exxx=End of line
mark
NET/GROSS key:
Expand or shorten
output data length
9 a
Signature ‘Signature’ and 3 line feed.
2 data sets can be printed in one line, the data printed at left side or right side. Some
data occupy one line (weight data, accumulated data, 4-digit year,etc.).
The printed data can include some symbols or characters with the numerical data.
A blank line can be set with the parameter “00”. At the beginning or ending of the
print data, line feed can be set by f63 or f64 separately using format 1 and 2.
The data number automatically increases by one after print out of the data group.
The first line is placed at the bottom of the line with the inverted print mode
(f65=1).
