Page 56 AD-4405A Weighing Indicator
15.3.1. Setting the Interval Time
Step 1 Press the SETPOINT(3) key while pressing the PRINT key to display intval
for 2 seconds.
Step 2 Select which interval time to set, using the following keys.
MODE key........The key to select serial output int 5i or printer output int pr .
ESC key...........The key to return to the weight display.
ENTER key ......The key to proceed to the time setting (Step 3).
Step 3 Set the interval time using the following keys. The key operation is the same as the
time setting.
0 - 9 key ..........The key to set the value at the blinking digit. Once set, the
blinking digit shifts to the right.
+/- key..............The key to shift the blinking digit to the right.
CLEAR key.......The key to reset the setting and display the interval time stored in
memory.
ESC key...........The key to return to Step 2 without changing the interval time
setting.
ENTER key ......The key to store the interval time setting and return to Step 2.
15.3.2. Interval Data Output / Print Output
Set the data output mode or print mode to “Manual mode” respectively to interval
data output or print out.
Pressing the START(7) key while pressing the PRINT key will start the interval
timer and output or print out the first data in the specified format.
The optional printer prints the interval time setting before printing the data.
Pressing the STOP (8) key while pressing the PRINT key will stop the interval
timer and output or print out the data.
The optional printer prints “Intv. Stop” before printing the data.
The optional printer replaces overload data with spaces except for the decimal
point.
15. Common Items for Printer and Data Output
