Page 34 AD-4405A Weighing Indicator
8. Accumulation
This function accumulates weighing data and stores the total data and the
accumulation count. The data is stored in non-volatile memory, and is not lost
even if the power is turned off.
8.1. Preparation and Specifications
Set the following parameters to use the accumulation function.
Set CF-function Cf08 to1 to enable the accumulation function.
Specify the method of accumulation and data at f20 of the F-functions.
Specify the inhibit region for accumulation at f21 of the F-functions.
Selection of Accumulation Mode, F20 of the F-functions
There are two methods of accumulation; manual accumulation using the M+ key
and automatic accumulation.
The data to accumulate can be selected from "positive data only" or "both polarity data".
The data to accumulate can be selected from "result of comparison is OK only" or "all
results".
Accumulation Condition, F21 of the F-functions
In the case of manual accumulation mode, press the M+ key to accumulate
weight data when the STABLE mark is displayed.
Data can be accumulated after the weight data enters the "inhibit region for output".
When turning the display on, the accumulation mode takes the same action.
Inhibit region for accumulation
f21
Description
Add data anytime
f21 0
Stable data can be used anytime
Above 5 d
f21 1
Initial setting
Above 10 d
f21 2
Above 20 d
f21 3
Above 50 d
f21 4
Caution Do not set f21 to 0 for the automatic accumulation mode
If f21 is set to 0, the same data may be added two times or more.
Limitation of Accumulation Count and Total
The limitation of accumulation count is 999999.
The limitation of total is 999999 ignoring the decimal point.
If exceeding these limitations, the data is not accumulated.
Example: When the decimal point is set to "0.0", the limitation is "99999.9".
