Page 54 AD-4405A Weighing Indicator
15. Common Items for Printer and Data Output
There are some similar functions and operations for the printer and the serial data
output (RS-232C, RS-422/485 and the current loop).
Data output / print output mode
Data number (not available for the current loop)
Interval data output or print out (not available for the current loop)
15.1. Data Output / Print Mode
Description of "Stream Mode" (For data output)
Function f37=0, f40=0
Operation The data is output at each sampling (when refreshing the display).
Use this mode to output data to an external display (The data may not be
output due to timing of the baud rate and internal sampling rate) or to print
data by pressing the PRINT key on the printer.
The serial interface command can not be used at f40=0.
Description of "Manual Print"
Function f37=1, f40=1, f60=1
Operation When the PRINT key is pressed or the external input is set to output or print,
the stable weight data is output or printed just once.
The serial interface command can be used at f40=1.
Description of "Auto Print Mode"
Function f37=2 or 3, f40=2 or 3, f60=2 or 3,
Operation When the weight data enters the "inhibit region for output" and becomes
stable in the "permission region of output", the stable data is output or printed
just once. To use this mode, set f02 to 1 to 10, but not 0.
The serial interface command can be used at f40=2 or 3.
For weighing (and removing) each object and printing the data.
In case of f37=2, f40=2, f60=2
"Inhibit region for output" +5d. +5d < "permission region of output".
In case of f37=3, f40=3, f60=3
-5d "inhibit region for output" +5d.
"Permission region of output" < -5d, +5d < "permission region of output".
d: division (weighing interval) of the first range.
Description of "Accumulated Data Output/Print"
Function f37=4, f40=4, f60=4
Operation When accumulation (manual or automatic) is performed, data is output or
printed automatically with the accumulated data.
The serial interface command can be used at f40=4.
15. Common Items for Printer and Data Output
