Page 38 AD-4405A Weighing Indicator
Changing the Code Memory Number by External Input
The code memory number can be changed by external input from OP-05 or
OP-08.
Set f14 and f15 to 18. (OP-08 has only one input; set f15)
f13=18 : Inhibit reading EXT.2 and EXT.3 to prevent unintentional reading when
switching the codes.
EXT.2 (f14) EXT.3 (f15) Code Memory number
ON ON 1
OFF ON 2
ON OFF 3
OFF OFF 4
9. Code Memory
