A&D EK-4100i - 13. Specifications; 13-1. EK-i Series

35
13. SPECIFICATIONS
13-1. EK-i series
MODEL EK-120i EK-200i EK-300i EK-600i
Weight capacity 120 g 200 g 300 g 600 g
Min. display “d” 0.01 g 0.01 g 0.01 g 0.1 g
No. of samples 5, 10, 25, 50 or 100 pieces
Max. count *) 12,000 pcs 20,000 pcs 30,000 pcs 6000 pcs
Min. unit weight *) 0.01 g 0.01 g 0.01 g 0.1 g
Min. % display 0.1 %
Min. 100 % weight 1 g 1 g 1 g 10 g
Repeatability
(Std. deviation)
0.01 g 0.01 g 0.01 g 0.1 g
Linearity ±0.01 g ±0.01 g ±0.02 g ±0.1 g
Sensitivity drift ±20 ppm / °C (10°C~30°C / 50°F~86°F)
Display 7 segment LCD display with backlight (Character height 16 mm)
Display update 10 time per second
Operating temp. -10°C~40°C / 14°F~104°F, less than 85% R.H. (non-condensing)
Power supply AC adapter or optional Ni-MH battery pack
Battery operation Approximately 9 hours (backlight off)
Weighing pan size 110 mm ø
133mm x 170mm
Weight
(approximately)
1.1 kg 1.1 kg 1.1 kg 1.3 kg
Calibration weight
(factory setting)
120 g 200 g 300 g 600 g
MODEL EK-1200i EK-2000i EK-3000i EK-6000i EK-12Ki
Weight capacity 1200 g 2000 g 3000 g 6000 g 12 kg
Min. display “d” 0.1 g 0.1 g 0.1 g 1 g 1 g
No. of samples 5, 10, 25, 50 or 100 pieces
Max. count *) 12,000 pcs 20,000 pcs 30,000 pcs 6000 pcs 12,000 pcs
Min. unit weight *) 0.1 g 0.1 g 0.1 g 1 g 1 g
Min. % display 0.1 %
Min. 100 % weight 10 g 10 g 10 g 100 g 100 g
Repeatability
(Std. deviation)
0.1 g 0.1 g 0.1 g 1 g 1 g
Linearity ±0.1 g ±0.1 g ±0.2 g ±1 g ±1 g
Sensitivity drift ±20 ppm / °C (10°C~30°C / 50°F~86°F)
Display 7 segment LCD display with backlight (Character height 16 mm)
Display update 10 time per second
Operating temp. -10°C~40°C / 14°F~104°F, less than 85% R.H. (non-condensing)
Power supply AC adapter or optional Ni-MH battery pack
Battery operation Approximately 9 hours (backlight off)
Weighing pan size 133 mm x 170 mm
Weight
(approximately)
1.5 kg 1.5 kg 1.5 kg 1.5 kg 1.5 kg
Calibration weight
(factory setting)
1200 g 2000 g 3000 g 6000 g 12 kg
*) In case of “Umin 0” (factory setting)
