A&D EK-4100i - 13-2. EW-i Series

36
MODEL EK-410i EK-610i EK-4100i EK-6100i
Weight capacity 400 g 600 g 4000 g 6000 g
Min. display “d” 0.01 g 0.01 g 0.1 g 0.1 g
No. of samples 5, 10, 25, 50 or 100 pieces
Max. count *) 40,000 pcs 60,000 pcs 40,000 pcs 60,000 pcs
Min. unit weight *) 0.01 g 0.01 g 0.1 g 0.1 g
Min. % display 0.1 %
Min. 100 % weight 1 g 1 g 10 g 10 g
Repeatability
(Std. deviation)
0.01 g 0.01 g 0.1 g 0.1 g
Linearity ±0.02 g ±0.02 g ±0.2 g ±0.2 g
Sensitivity drift ±20 ppm / °C (10°C~30°C / 50°F~86°F)
Display 7 segment LCD display with backlight (Character height 16 mm)
Display update 10 time per second
Operating temp. -10°C~40°C / 14°F~104°F, less than 85% R.H. (non-condensing)
Power supply AC adapter or optional Ni-MH battery pack
Battery operation Approximately 9 hours (backlight off)
Weighing pan size 110 mm ø
133mm x 170mm
Weight
(approximately)
1.1 kg 1.1 kg 1.5 kg 1.5 kg
Calibration weight
(factory setting)
400 g 600 g 4000 g 6000 g
*) In case of “Umin 0” (factory setting)
13-2. EW-i series
MODEL EW-150i EW-1500i EW-12Ki
Weight capacity
30 g 60 g 150 g 300 g 600 g 1500 g 3 kg 6 kg 12 kg
Min. display ”d”
0.01g 0.02g 0.05g 0.1g 0.2g 0.5g 1g 2g 5g
No. of samples 5, 10, 25, 50 or 100 pieces
Max. count *) 15,000 pcs 15,000 pcs 12,000 pcs
Min. unit weight *) 0.01 g 0.1 g 1 g
Min. % display 0.1 %
Min. 100 % weight 1 g 10 g 100 g
Repeatability
(Std. deviation)
0.01g 0.02g 0.05g 0.1g 0.2g 0.5g 1g 2g 5g
Linearity
±0.01g ±0.02g ±0.05g ±0.1g ±0.2g ±0.5g ±1g ±2g ±5g
Sensitivity drift ±20 ppm / °C (10°C~30°C / 50°F~86°F)
Display 7 segment LCD display with backlight (Character height 16 mm)
Display update 10 time per second
Operating temp. -10°C~40°C / 14°F~104°F, less than 85% R.H. (non-condensing)
Power supply AC adapter or optional Ni-MH battery pack
Battery operation Approximately 9 hours (backlight off)
Weighing pan size 110 mm ø 133 mm x 170 mm
Weight
(approximately)
1.1 kg 1.5 kg 1.5 kg
Calibration weight
(factory setting)
150 g 1500 g 12 kg
*) In case of “Umin 0” (factory setting)
