LCD DISPLAY SCREENS
MODGAS-XWR2 Technical Guide
26
Setpoint & Force Valve Screens
Force Valve Screens
Refer to the following map when navigating through the Force Valve
Screens. From the FORCE VALVE Screen, press <ENTER>. At the
V1 and V2 FORCE ON/OFF screens, press the
<UP> arrow key to
turn the FORCE MODE on and press the
<DOWN> arrow key to turn
the FORCE MODE o. Use the <UP> and <DOWN> arrow keys to
increase and decrease the percentage.
FORCE
VALVES
STAGE 1 FORCE
ON/OFF
V1 POSITION
X%
FORCE VALVE 1 PERCENTAGE
This screen only appears when Stage 1 Force is on.
Press the <UP> button to turn the Force Mode on. Press the <DOWN>
button to turn the Force Mode o.
Press the <UP> button to increase the percentage. Press the <DOWN>
button to decrease the percentage.
NOTE: When you turn the Force Mode back o or after 10 minutes of no
keypad input, the valve will go to zero and the relays will turn o.
STAGE 2 FORCE
ON/OFF/DISABLED
V2 POSITION
X%
FORCE VALVE 2 PERCENTAGE
This screen only appears when Valve 2 Force is on.
Press the <UP> button to turn the Force Mode on. Press the <DOWN>
button to turn the Force Mode o. If the screen says disabled, on/o
selection is not possible.
Press the <UP> button to increase the percentage. Press the <DOWN>
button to decrease the percentage.
STAGE 3
FORCE ON/OFF
STAGES 3 & 4 FORCE ON / OFF
The Stages Force Screens will allow you to force each stage on or o.
Press the <UP> button to turn the Force Mode on. Press the <DOWN>
button to turn the Force Mode o.
STAGE 4
FORCE ON/OFF
RESET SP
40-200°F
5-93°C
RESET HEATING SUPPLY AIR SETPOINT
This is maximum temperature at which the Supply Air Temperature will
reset to. The Setpoint Screen will display only in stand-alone mode.
Minimum Default Maximum
40°F
5°C
120°F
49°C
200°F
93°C
