LCD SCREENS
System Status Screens
System Status Screens
Refer to the following map when navigating through the System
Status Screens. From the SYSTEM STATUS Screen, press
<ENTER> to scroll through the screens.
SYSTEM
STATUS
MODE
SYSTEM MODE
MIN RUN, OFF, COOLING, HEATING, DEHUM, or FORCED
COMP A1
ON/OFF or
MODULATING %
COMPRESSOR 1
ON/OFF or MODULATING %
FIXED ON/OFF: Compressor is on or o󰀨.
MODULATING %: 0-100%
COMP A2
ON/OFF or HI
SPEED/LO SPEED
COMPRESSOR 2
ON, OFF, HI SPEED, or LO SPEED
FIXED ON/OFF: Compressor is on or o󰀨.
TWO STEP: High Speed or Low Speed
CONDFAN1
OFF
CONDENSER 1
COND FAN, NOT USED, or OFF
COND FAN MODULATING PERCENTAGE: 0-100%
CONDFAN2
OFF
CONDENSER 2
COND FAN, NOT USED, or OFF
COND FAN MODULATING PERCENTAGE: 0-100%
EXV A1
0%
EXV VALVE POSITION
0-100%
EXV 2
0% or NOT USED
EXV VALVE 2 POSITION
0-100% or NOT USED
