Setpoint Status Screens
Setpoint Status Screens
Refer to the following map when navigating through the Setpoint
Status Screens. From the SETPOINT STATUS Screen, press
<ENTER> to scroll through the screens.
SETPOINT
STATUS
HEADPR 1
340 PSIG
HEAD PRESSURE SETPOINT 1
Valid range is 260-475 psig. Default is 340 psig.
HEADPR 2
340 PSIG
HEAD PRESSURE SETPOINT 2
Valid range is 260-475 psig. Default is 340 psig.
SPRHT SP
15
SUPERHEAT SETPOINT SETTING
Valid range is 1-30ºF. Default is 15ºF.
LOW SUCT
95 PSIG
LOW SUCTION PRESSURE SETPOINT SETTING
Default is 95 psig.
COILT SP
40
COIL TEMPERATURE SETPOINT SETTING
Valid range is 35-70ºF. Default is 40ºF.
GLYCOL %
40
GLYCOL PERCENTAGE SETPOINT SETTING
Valid range is 35-70%. Default is 40%.
Only appears if congured as WSHP.
LOW H2O
XX.XºF
LOW H
2
O SETPOINT SETTING
Automatically resets based on Glycol %.
Only appears if congured as WSHP.
