32 RSMVQ Technical Guide
APPENDIX A: SYSTEM CONFIGURATION
Two Condensers Per Module
Two Condensers Per Module
In Two Condensers Per Module wiring configuration, the
Condenser Signals are wired to AO1 and AO2 and RLY3 and
RLY4.
Refer to the gures below for Prism 2 conguration and Modular
Service Tool Screen selection.
RSMVQ Condenser Options Conguration Screen
Select the “2 Cond per RSMV” option on the above handheld
Modular Service Tool screen.
RSM#1 CONFIGURATION
Condenser Options
2 Cond per RSMV
USE < or > TO CHANGE
Figure 11: Prism 2 - Two Condensers Module Conguration
