25
RSMV
Q T
echnical Guide
LCD
SCREENS
Danfoss VFD Screens
C1 HOURS
COMPRESSOR RUNNING HOURS
Compressor running hours read from VFD.
VFD HRS
VFD RUNNING HOURS
VFD running hours read from VFD.
MODEL#
MODEL NUMBER
Compressor model number read from VFD.
DRIVE#
DRIVE NUMBER
T
ype of Danfoss VFD - CDS803 or CDS303.
24
26
