RSMVQ2R Technical Guide
LCD SCREENS
Sensor Status Screens
Sensor Status Screens
Refer to the following map when navigating through the Sensor
Status Screens. From the SENSOR STATUS Screen, press
<ENTER> to scroll through the screens.
SENSOR
STATUS
SUCTION
XXX PSIG
SUCTION PRESSURE READING FROM INPUT
HEAD PR1
XXX PSI
HEAD PRESSURE 1 READING FROM INPUT
HEAD PR2
XXX PSI
HEAD PRESSURE 2 READING FROM INPUT
SUPRHT 1
XX DEG
CURRENT SUPERHEAT 1 CALCULATION
SUPRHT 2
XX DEG
CURRENT SUPERHEAT 2 CALCULATION
DISCTEMP
XX DEG
DISCHARGE LINE TEMP 1 READING FROM INPUT
Only appears if congured for DANFOSS.
COIL 1
XX DEG
COIL TEMPERATURE 1
COIL 2
XX DEG
COIL TEMPERATURE 2
CALC CT
XX DEG
CALCULATED COIL TEMPERATURE
(Saturated Temperature)
SATCOIL2
XX DEG
SATURATION LINE: TEMP 2 READING FROM INPUT
Only appears if congured for two compressors/circuits.
