RSMVQ2R Technical Guide
APPENDIX A: SYSTEM CONFIGURATION
Single Condenser Per Module A
Single Condenser Per Module A
In Single Condenser Per Module wiring conguration, the
Condenser Signal is wired to AO1 and the Condenser Relay
RLY3 is enabled. Refer to the figures below for Prism 2
conguration and Modular Service Tool Screen selection.
RSMVQ2R Condenser Options Conguration Screen
Select the “1 Condenser per RSMV” option on the above Hand
Held Service Tool Screen.
RSM#1-4 CONFIGURATION
Condenser Options
1 Cond per RSMV
USE < or > TO CHANGE
Figure 10: Prism 2 Single Condenser Module A Conguration
