RSMVQ2R Technical Guide
APPENDIX A: SYSTEM CONFIGURATION
Unit Tonnage Selection and Compressor Type Specication Table
Unit Tonnage Selection
You must enter the tonnage for the unit you are controlling.
Please refer to Table 8, this page to gure out the unit tonnage
for the compressor(s) on your system. This is found on the RSMV
Conguration Screen. Compressor Type Specications
Refer to Table 8, this page for compressor type unit tonnage
and minimum and maximum compressor speeds.
RSMV-Q Tonnage Selection
Compressor Tonnage Rating
0Tons
Figure 15: RSMVQ2R Unit Tonnage Selection
COMPRESSOR TYPE SPECIFICATIONS TABLE
Compressor Type(s) Unit Tonnage
Minimum VFD
Compressor Speed* (RPM)
Maximum VFD
Compressor Speed*
(RPM)
Single Danfoss CDS803 VFD 7 900 5250
Single Danfoss CDS303 VFD 8 1000 5100
Single Copeland EVxxxx Modular VFD Determined by Compressor Model
Single Copeland EVCxxx Packaged VFD Determined by Compressor Model
Compressor 1 - Danfoss CDS803 VFD
Compressor 2 - On/O󰀨
9 900 5100
13 900 5610
Compressor 1 - Danfoss CDS803 VFD
Compressor 2 - Two Step
11 900 5100
Compressor 1 - Danfoss CDS303 VFD
Compressor 2 - On/O󰀨
N/A N/A N/A
Compressor 1 - Danfoss CDS303 VFD
Compressor 2 - Two Step
15 1000 5800
Compressor 1 - Copeland EVCxxx Packaged VFD
Compressor 2 - On/O󰀨
30 1200 4700
Compressor 1 - Copeland EVCxxx Packaged VFD
Compressor 2 - Two-Step
20 1000 4900
25 1200 5500
NOTE: *Speed limits given are before compressor envelope limits are set. See page 11 for envelope limit information.
Table 8: Compressor Type Specication Table
