RSMVQ2R Technical Guide
LCD SCREENS
Danfoss VFD Screens
Danfoss VFD Screens
Refer to the following map when navigating through the Danfoss
VFD Screens. From the Danfoss Comp Screen, press <ENTER>
to scroll through the screens.
DANFOSS
COMP
CONNECT?
CONNECTION STATUS
YES or NO. VFD is connected and communicated to the RSMVQ2R.
MB RETRY
MB RETRY
Counts up if it is missing communication packet information.
MB VALID
MB VALID
Counts up if it receives good communication packet information.
VFD STAT
VFD COMPRESSOR
Displays a value read from VFD showing status and conguration
information. Then it will display each bit of information separately.
COMMAND%
COMPRESSOR COMMAND
Compressor percentage commanded to VFD.
MAX REF
MAXIMUM SPEED
Maximum speed programmed into the VFD in RPM.
MIN REF
MINIMUM SPEED
NOT = 0! or CONFIRMED
Minimum speed programmed into the VFD. For proper speed
command this should always say conrmed meaning it is set to zero.
NO ALARMS or
ALARM CODE
ALARM CODE (8 of them)
Alarm codes are read from the VFD.
CURRENT
XX AMPS
CURRENT AMPS
Live current read from VFD in Amps.
C1 HOURS
COMPRESSOR RUNNING HOURS
Compressor running hours read from VFD.
VFD HRS
VFD RUNNING HOURS
VFD running hours read from VFD.
