RSMVQ2R Technical Guide
LCD SCREENS
Setpoint Status Screens
Setpoint Status Screens
Refer to the following map when navigating through the Setpoint
Status Screens. From the SETPOINT STATUS Screen, press
<ENTER> to scroll through the screens.
SETPOINT
STATUS
HEADPR 1
340 PSI
HEAD PRESSURE SETPOINT 1
Valid range is 260-475 PSI. Default is 340 PSI.
HEADPR 2
340 PSI
HEAD PRESSURE SETPOINT 2
Valid range is 260-475 PSI. Default is 340 PSI.
SPRHT SP
15
SUPERHEAT SETPOINT SETTING
Valid range is 1-30 degrees. Default is 15 degrees.
LOW SUCT
95 PSI
LOW SUCTION PRESSURE SETPOINT SETTING
Default is 95 PSI.
COILT SP
40
COIL TEMPERATURE SETPOINT SETTING
Valid range is 35-70 degrees. Default is 40 degrees.
GLYCOL %
40
GLYCOL PERCENTAGE SETPOINT SETTING
Valid range is 35-70%. Default is 40%.
Only appears if congured as WSHP.
LOW H2O
XX.XºF
LOW H2O SETPOINT SETTING
Automatically resets based on Glycol %.
Only appears if congured as WSHP.
