AAON WH Series User Manual

10
WSHP Series Feature String Nomenclature
Unit Configuration
:
Accessory Options
Gen
Major Rev
Size
Series
Minor Rev
Voltage
Eff. Level
Comp Style
Loop Type
Coil Type
Heat Type
Heat Staging
1
2
3A
3B
4
5
6A
6B
7
8
9
10
11
12
13
14
15
16
WH A
-
024
-
C
-
0
-
3
-
1
-
0
0
0
-
0
0
:
0
0
-
0
A
-
0
0
-
0
0
-
0
0
0
0
0
-
0
0
0
0
0
MODEL OPTIONS
Generation and Orientation
WH = Horizontal Water-Source Heat Pump
Major Revision
A
Unit Size
006 = 6,000 Btu/hr = ½ ton
009 = 9,000 Btu/hr = ¾ ton
012 = 12,000 Btu/hr = 1 ton
015 = 15,000 Btu/hr = 1 ¼ ton
018 = 18,000 Btu/hr = 1 ½ ton
024 = 24,000 Btu/hr = 2 ton
030 = 30,000 Btu/hr = 2 ½ ton
036 = 36, 000 Btu/hr = 3 ton
042 = 42,000 Btu/hr = 3 ½ ton
048 = 48,000 Btu/hr = 4 ton
060 = 60,000 Btu/hr = 5 ton
072 = 72,000 Btu/hr = 6 ton
096 = 96,000 Btu/hr = 8 ton
120 = 120,000 Btu/hr = 10 ton
150 = 150,000 Btu/hr = 12 ½ ton
Series
A = A Cabinet (006, 009 & 012)
B = B Cabinet (015 & 018)
C = C Cabinet (024 & 030)
D = D Cabinet (036 & 042)
E = E Cabinet (048 & 060)
F = F Cabinet (072 & 096)
G = G Cabinet (120 & 150)
Minor Revision
0 = Minor Revision 0
Voltage
3 = 460V/3Φ/60Hz
4 = 575V/3Φ/60Hz
A = 265V/1Φ/60Hz
B = 115V/1Φ/60Hz
C = 208-230V/1Φ/60Hz
D = 208-230V/3Φ/60Hz
Efficiency Level
1 = Std Efficiency Compact Box with PSC Motor
2 = Std Efficiency Compact Box with ECM Motor
4 = Std Efficiency Compact Box with Two-Step
Compressor & ECM Motor
Compressor Style
0 = R-410A On/Off Compressor - Heat Pump
A = R-410A Two-Step Compressor - Heat Pump
Loop Type
0 = Water Loop (Cooling Tower Only, EWT ≥ 60°F)
A = Ground Loop Application
B = Ground Water Application
Coil Type
0 = Copper Coaxial Refrigerant-to-Water Heat
Exchanger + Microchannel Air Coil
B = Cupronickel Coaxial Refrigerant-to-Water Heat
Exchanger + Microchannel Air Coil
Heat Type
0 = No Heating
Heating Staging
0 = No Heating
1: Unit Orientation
0 = Right Hand Return + Left Hand Supply
A = Right Hand Return + End Supply
B = Left Hand Return + Right Hand Supply
C = Left Hand Return + End Supply
2: Supply Fan
0 = Standard Fan + PSC Motor
B = Standard Fan + ECM Motor
