Dip Switch SW1
Fan-Speed Dehumidification Selections
Pos 9
Fan-Speed Dehum Disabled
OFF
Fan-Speed Dehum Enabled
ON
POS 1 through 8 are not currently used.
Dip Switch SW2
1. Waterside Economizer Enable
Pos 1
WSE Disabled
OFF
WSE Enabled
ON
2. Waterside Economizer Temperature Enable Setpoint Selection
Pos 2
Pos 3
Pos 4
Pos 5
45°F
OFF
OFF
OFF
OFF
46°F
OFF
OFF
OFF
ON
47°F
OFF
OFF
ON
OFF
48°F
OFF
OFF
ON
ON
49°F
OFF
ON
OFF
OFF
50°F
OFF
ON
OFF
ON
51°F
OFF
ON
ON
OFF
52°F
OFF
ON
ON
ON
53°F
ON
OFF
OFF
OFF
54°F
ON
OFF
OFF
ON
55°F
ON
OFF
ON
OFF
56°F
ON
OFF
ON
ON
57°F
ON
ON
OFF
OFF
58°F
ON
ON
OFF
ON
59°F
ON
ON
ON
OFF
60°F
ON
ON
ON
ON
Relay Status LEDs
FAN HIGH = Fan High Speed Relay
COMP2 = Compressor Stage 2 Relay
ALARM = Alarm Relay
WTR ECON = Waterside Economizer Relay
REHEAT - Reheat Relay
