AAton 35-III - Motor Side

1.4 MOTORS SIDE
31 Eyepiece Shutter blocks light when operator’s eye is away from the viewfinder
32 Lemo6 Connector
33 Lemo8 Connector
34 Led Indicators
35 Handgrip Run/Test Switch provides camera run and full frame inching
36 Lemo2 Connector
37 Magazine’s Take-up Core Motor
38 Handgrip T-Screw
39 Mag Release Lever
40 Magazine’s Sprockets and Camera Pulldown Claw Motor
15
GENERAL OVERVIEW
31
32
33
34
35
36
37
38
39
40
