Appendix A – Complete Parameter Settings
ACH 500 Programming Manual A-7
30 PROTECTION/INFORMAT
30.1 FAULT FUNCTION
30.1.1 SERIAL FAULT FUNC STOP; PRE SPEED7
30.1.2 AI <MIN FUNCTION NO; WARNING; FAULT; PRE SPEED7; LAST SPEED
30.1.3 MOT TEMP FLT FUNC NO; WARNING; FAULT
30.1.4 MOTOR THERM TIME 300s – 10000s
30.1.5 MOTOR LOAD CURVE 50% – 150%
30.1.6 ZERO SPEED LOAD 40% – MOTOR LOAD CURVE
30.1.7 BREAK POINT 1 Hz – 500 Hz
30.1.8 STALL FUNCTION NO; WARNING; FAULT
30.1.9 STALL CURRENT 0 – 1.5 x I
N
30.1.10 STALL TIME/FREQ 10s/15 Hz; 20s/25 Hz; 30s/35 Hz
30.1.11 UNDERLOAD FUNC NO; WARNING FAULT
30.1.12 UNDERLOAD TIME 0 – 600s
30.1.13 UNDERLOAD CURVE 1 – 5
30.2 AUTOMATIC RESET
30.2.1 NUMBER OF RESETS 0 – 5
30.2.2 TIME WINDOW 1s – 180s
30.2.3 TIME BETW. RESET
ATTEMPTS
0s – 120s
30.2.4 OVERVOLTAGE NO; YES
30.2.5 UNDERVOLTAGE NO; YES
30.2.6 OVERCURRENT NO; YES
30.2.7 AI SIGNAL <MIN NO; YES
Parameter Alternative Settings
Custom
Setting
