30.3 SUPERVISION
30.3.1 OUTPUT FREQ 1 FUNC NO; LOW LIMIT; HIGH LIMIT
30.3.2 OUTPUT FREQ 1 LIM 0 Hz – 500 Hz (ACS 501); 0 Hz – 120 Hz (ACS 502)
30.3.3 OUTPUT FREQ 2 FUNC NO; LOW LIMIT; HIGH LIMIT
30.3.4 OUTPUT FREQ 2 LIM 0 Hz – 500 Hz (ACS 501); 0 Hz – 120 Hz (ACS 502)
30.3.5 CURRENT FUNCTION NO; LOW LIMIT; HIGH LIMIT
30.3.6 CURRENT LIMIT 0 – 2 x I
N
(ACS 500)
30.3.7 REF1 FUNCTION NO; LOW LIMIT; HIGH LIMIT
30.3.8 REF1 LIMIT 0 Hz – 500 Hz (ACS 501); 0 Hz – 120 Hz (ACS 502)
30.3.9 REF2 FUNCTION NO; LOW LIMIT; HIGH LIMIT
30.3.10 REF2 LIMIT 0% – 100%
30.3.11 SUPERVIS MESSAGES OFF; ON
30.4 INFORMATION
30.4.11 CRI PROG VERSION (Version in Drive)
30.4.2 MC PROG VERSION (Version in Drive)
30.4.3 TEST DATE (Date Tested)
40 APPLICATION
PARAMETERS
(CAN BE SEEN ONLY WITH APPLICATION MACROS)
40.1 PI-CONTROL (CAN BE SEEN ONLY WITH PI-CONTROL MACRO)
40.1.1 PI-CONT GAIN 3% – 800%
40.1.2 PI-CONT I-TIME 0.02s – 320s
40.1.3 PI-CONT MIN LIMIT 0 Hz – PI-CONT MAX LIMIT
40.1.4 PI-CONT MAX LIMIT 0 Hz – 500 Hz (ACS 501); 0 Hz – 120 Hz (ACS 502)
40.1.5 ERROR VALUE INVERT NO; YES
40.1.6 ACTUAL VALUE SEL ACT1; ACT1-ACT2; ACT1+ACT2; ACT1*ACT2
40.1.7 ACTUAL 1 INPUT AI1; AI2
40.1.8 ACTUAL 2 INPUT AI1; AI2
40.1.9 ACT 1 MIN SCALE -1600.0% – 1600.0%
40.1.10 ACT 1 MAX SCALE -1600.0% – 1600.0%
40.1.11 ACT 2 MIN SCALE -1600.0% – 1600.0%
40.1.12 ACT 2 MAX SCALE -1600.0% – 1600.0%
Parameter Alternative Settings
Custom
Setting
To Next Page
