ACS 400 User’s Manual 67
1305 MAXIMUM AI2 0 - 100 % 1 % 100 %
1306
FILTER AI2 0 - 10 s 0.1 s 0.1 s
Group 14
RELAY OUTPUTS
1401
RELAY OUTPUT 10 - 31 1 * áá
1402 RELAY OUTPUT 20 - 31 1 * áá
1403 RELAY 1 ON DELAY 0 - 3600 s 0.1 s; 1 s 0 s
1404
RELAY 1 OFF DELAY 0 - 3600 s 0.1 s; 1 s 0 s
1405
RELAY 2 ON DELAY 0 - 3600 s 0.1 s; 1 s 0 s
1406
RELAY 2 OFF DELAY 0 - 3600 s 0.1 s; 1 s 0 s
Group 15
ANALOG OUTPUT
1501
AO CONTENT 102 - 137 1 103
1502
AO CONTENT MIN -*0.0 Hz
1503 AO CONTENT MAX -** á
1504 MINIMUM AO 0.0 - 20.0 mA 0.1 mA 0 mA
1505
MAXIMUM AO 0.0 - 20.0 mA 0.1 mA 20.0 mA
1506
FILTER AO 0 - 10 s 0.1 s 0.1 s
Group 16
SYSTEM CONTROLS
1601
RUN ENABLE 0 - 6 1 * áá
1602 PARAMETER LOCK 0 - 2 1 1 (OPEN)
1604
FAULT RESET SEL 0 - 7 1 * áá
1605 LOCAL LOCK 0 - 1 1 0 (OPEN)
1607
PARAM. SAVE 0 - 1 1 0 (DONE)
1608
DISPLAY ALARMS 0-1 1 0 (NO)
Group 20
LIMITS
2003 MAX CURRENT 0.5*I
N
- 1.5...1.7*I
N
** 0.1 A 1.5*I
N
**
2005
OVERVOLT CTRL 0 - 1 1 1 (ENABLE)
2006
UNDERVOLT CTRL 0 - 2 1 1 (ENABLE TIME)
2007
MINIMUM FREQ 0 - 250 Hz 1 Hz 0 Hz
2008 MAXIMUM FREQ 0 - 250 Hz 1 Hz * áá
Group 21
START/STOP
2101
START FUNCTION 1 - 4 1 1 (RAMP) á
2102 STOP FUNCTION 1 - 2 1 1 (COAST)
2103
TORQ BOOST CURR 0.5*I
N
- 1.5...1.7*I
N
** 0.1 A 1.2*I
N
** á
2104 STOP DC INJ TIME 0 - 250 s 0.1 s 0 s
2105
PREMAGN SEL 0 - 6 1 áá
2106 PREMAGN MAX TIME 0.0 - 130.0 s 0.1 s 2.0 s
2107
START INHIBIT 0 - 1 1 1 (ON)
Code Name Range Resolution Default User S M
