68 ACS 400 User’s Manual
Group 22
ACCEL/DECEL
2201
ACC/DEC 1/2 SEL 0 - 5 1 * áá
2202 ACCELER TIME 1 0.1 - 1800 s 0.1; 1 s 5 s
2203 DECELER TIME 1 0.1 - 1800 s 0.1; 1 s 5 s
2204 ACCELER TIME 2 0.1 - 1800 s 0.1; 1 s 60 s
2205 DECELER TIME 2 0.1 - 1800 s 0.1; 1 s 60 s
2206
RAMP SHAPE 0 - 3 1 0 (LINEAR)
Group 25
CRITICAL FREQ
2501
CRIT FREQ SEL 0 - 1 1 0 (OFF)
2502
CRIT FREQ 1 LO 0 - 250 Hz 1 Hz 0 Hz
2503
CRIT FREQ 1 HI 0 - 250 Hz 1 Hz 0 Hz
2504
CRIT FREQ 2 LO 0 - 250 Hz 1 Hz 0 Hz
2505
CRIT FREQ 2 HI 0 - 250 Hz 1 Hz 0 Hz
Group 26
MOTOR CONTROL
2603
IR COMPENSATION 0 - 60 V 400 V units 1 V 10 V
2604
IR COMP RANGE 0 - 250 Hz 1 Hz 60 Hz
2605
LOW NOISE 0 - 1 1 0 (OFF) á
2606 U/f RATIO 1 - 2 1 1 (LINEAR) á
2607 SLIP COMP RATIO 0 - 250 % 1 % 0 % á
Group 30
FAULT FUNCTIONS
3001
AI<MIN FUNCTION 0 - 3 1 1 (FAULT)
3002
PANEL LOSS 1 - 3 1 1 (FAULT)
3003
EXTERNAL FAULT 0 - 5 1 0 (NOT SEL)
3004
MOT THERM PROT 0 - 2 1 1 (FAULT)
3005
MOT THERM TIME 256 - 9999 s 1 s 500 s
3006
MOT LOAD CURVE 50 - 150 % 1 % 100 %
3007
ZERO SPEED LOAD 25 - 150 % 1 % 70 %
3008
BREAK POINT 1 - 250 Hz 1 Hz 35 Hz
3009
STALL FUNCTION 0 - 2 1 0 (NOT SEL)
3010
STALL CURRENT 0.5*I
N
- 1.5...1.7*I
N
** 0.1 A 1.2* I
N
**
3011
STALL FREQ HI 0.5 - 50 Hz 0.1 Hz 20 Hz
3012
STALL TIME 10...400 s 1 s 20 s
3013
UNDERLOAD FUNC 0 - 2 1 0 (NOT SEL)
3014
UNDERLOAD TIME 10...400 s 1 s 20 s
3015
UNDERLOAD CURVE 1 - 5 1 1
3017
GROUND FAULT 1 - 2 1 1 (FAULT)
3022
AI1 FLT LIMIT 0 - 100 % 1 % 0 %
3023
AI2 FLT LIMIT 0 - 100 % 1 % 0 %
Code Name Range Resolution Default User S M
