ACS 400 User’s Manual 69
Group 31
AUTOMATIC RESET
3101
NR OF TRIALS 0 - 5 1 0
3102
TRIAL TIME 1.0 - 180.0 s 0.1 s 30 s
3103
DELAY TIME 0.0 - 3.0 s 0.1 s 0 s
3104
AR OVERCURRENT 0 - 1 1 0 (DISABLE)
3105
AR OVERVOLTAGE 0 - 1 1 0 (DISABLE)
3106
AR UNDERVOLTAGE 0 - 1 1 0 (DISABLE)
3107
AR AI<MIN 0 - 1 1 0 (DISABLE)
Group 32
SUPERVISION
3201
SUPERV 1 PARAM 102 - 137 1 103
3202
SUPERV 1 LIM LO --0
3203
SUPERV 1 LIM HI --0
3204
SUPERV 2 PARAM 102 - 137 1 103
3205
SUPERV 2 LIM LO --0
3206
SUPERV 2 LIM HI --0
Group 33
INFORMATION
3301 SW VERSION 0.0.0.0 - f.f.f.f - -
3302
TEST DATE yy.ww - -
Group 34
PROCESS VARIABLES
3401
DISPLAY SEL 1 - 2 1 1(STANDARD)
3402
P VAR 1 SEL 102 - 137 1 104
3403
P VAR 1 MULTIP 1 - 9999 1 1
3404
P VAR 1 DIVISOR 1 - 9999 1 1
3405
P VAR 1 SCALING 0 - 3 1 1
3406
P VAR 1 UNIT 0 - 31 1 1 (A)
3407
P VAR 2 SEL 102 - 137 1 103
3408
P VAR 2 MULTIP 1 - 9999 1 1
3409
P VAR 2 DIVISOR 1 - 9999 1 1
3410
P VAR 2 SCALING 0 - 3 1 1
3411
P VAR 2 UNIT 0 - 31 1 3 (Hz)
Code Name Range Resolution Default User S M
