CHAPTER 10 – PREVENTIVE AND CORRECTIVE MAINTENANCE 162
Profibus interface
—
References
—
10-8 Profibus interface
—
10-8
During start-up LED
Master MSG DDCS
Power-on Off Off Green then red then off
Off Green then red then off Off
Green then red then off Off Off
DDCS link initialization Off Off Flashing green then green
Transfer-rate detection Flashing green then green Off Green
Communication established Green Flashing green then green Green
Operation Green Green Green
—
Table 10-4 Profibus LED description
LED Cause
Master MSG DDCS
Red Red Off RAM test failure
Off Red Red ROM test failure
Last valid state Last valid state red DDCS link failure
Green Flashing red Flashing green Communication failure
Flashing red Red Flashing green Link failure
1. Fib
er-optic connectors for co
mmunication cable to
the
drive
•TX
D = transmitter
•RXD
= receiver
2. Res
et button for initialization
of module
3. Sta
tus LEDs
4. Bus
-cable terminals
1
2
3
4
