TIA portal
Contents of this chapter
This chapter provides the examples for configuring S7-300 and S7-1200 series PLC. You can configure
S7-300, S7-400, S7-1200 and S7-1500 series PLC using TIA portal.
Configuring PC IP address
To configure PC IP address, follow these steps:
Navigate to Control Panel → Network and Sharing Center → Local Area Connection in the PC.
1. In the Local Area Connection Status window, click Properties.
Figure 48 LAC
4

ABB ACS355 series Specifications

General

Power Range	0.37 to 22 kW
Protection Class	IP20
Output Frequency	0 to 500 Hz
Braking Chopper	Built-in
Control Method	Scalar control, Vector control
Ambient Temperature	-10 to +50 °C
Communication Protocols	Modbus, CANopen
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature
Cooling Method	Air-cooled
Number of Phases	3-phase
