Update Notice
7
NEW (page 109): ASTO-11C
NEW (page 109): Ambient conditions
Modules with option +Q967: the installation site altitude in operation is 0 to 2000 m.
CHANGED (page 117): Dimensional drawings / What this chapter contains
Dimensional drawings of the ACS800-04/U4, flange mounting kits, AGPS board and
ASTO board are shown below. The dimensions are given in millimetres and [inches].
NEW/CHANGED (page 129): Dimensional drawings / AGPS and ASTO
boards
The dimensions of the AGPS and ASTO boards are the same.
Nominal input voltage 24 V DC
Nominal input current 40 mA (20mA per channel)
X1 terminal sizes 4 x 2.5 mm
2
Nominal output current 0.4 A
X2 terminal block type JST B4P-VH
Ambient temperature 0...50°C
Relative humidity Max. 90%, no condensation allowed
Dimensions (with
enclosure)
167 x 128 x 52 mm (Height x Weight x Depth)
Weight (with enclosure) 0.75 kg
Operation
installed for stationary use
Installation site altitude
[...]
Modules with option +Q967:
0 to 2000 m
