Technical data
107
Cable entries
Brake resistor, input and motor cable (per phase) terminal sizes and tightening
torques are given below
.
* 6 AWG rigid solid cable, 8 AWG flexible stranded cable
** with cable lugs 6...2/0 AWG, tightening torque 14.8...29.5 lbf ft. Cable lugs are not included in the
delivery. See page 64.
Dimensions, weights and noise
* Depth depends on the options included in the drive.
Frame
size
U1, V1, W1, U2, V2, W2, R+, R
- Earthing PE
Maximum wire size Tightening torque Maximum wire size Tightening torque
AWG lbf ft AWG lbf ft
R2 up to 6 * 0.9…1.1 up to 8 1.1
R3 up to 6 * 0.9...1.1 up to 8 1.1
R4 up to 4 1.5…3.0 up to 5 2.2
R5 10...2/0 11.1 10...2/0 11.1
R6 3/0...2×4/0 ** 14.8...29.5 4/0 5.9
Frame size Height Width Depth* Weight Noise
in. in. in. lb dB
R2 14.57 6.5 7.6...8.9 18 62
R3 16.54 6.81 9.11...10.43 29 62
R4 19.29 9.45 9.93...10.69 53 62
R5 23.70 10.43 10.85...11.11 71 65
R6 27.56 11.81 15.71 141 65
Input power connection
Voltage (U
1
) 208/220/230/240 V AC 3-phase ±10% for 230 V AC units
380/400/415 V AC 3-phase ±10% for 400 V AC units
380/400/415/440/460/480/500 V AC 3-phase ±10% for 500 V AC units
525/550/575/600/660/690 V AC 3-phase ±10% for 690 V AC units
Rated conditional short-
circuit current (IEC 60439-1)
65 kA when protected by fuses given in the IEC data fuse tables.
Short-circuit current
protection (UL 508 C
CSA C22.2 No. 14-05)
US and Canada: The drive is suitable for use on a circuit capable of delivering not more
than 100 kA rms symmetrical amperes at the drive nominal voltage when protected by
fuses given in the NEMA data fuse table.
Frequency 48 to 63 Hz, maximum rate of change 17%/s
Imbalance Max. ±3% of nominal phase to phase input voltage
Fundamental power factor
(cos phi
1
)
0.98 (at nominal load)
