Cable types
Cable sizing is based on NEC Table 310-16 for copper wires, 75 °C (167 °F) wire insulation at 40 °C
(104 °F) ambient temperature. Not more than three current-carrying conductors in raceway or cable or
earth (directly buried). For other conditions, dimension the cables according to local safety regulations,
appropriate input voltage and the load current of the drive.
Three-phase supply voltage 525 V, 575 V, 600 V
-0011-7 R4 10 20 600 Bussmann JJS-20 T
-0016-7 R4 13 20 600 Bussmann JJS-20 T
-0020-7 R4 19 30 600 Bussmann JJS-30 T
-0025-7 R4 21 30 600 Bussmann JJS-30 T
-0030-7 R4 29 45 600 Bussmann JJS-45 T
-0040-7 R4 32 45 600 Bussmann JJS-45 T
-0050-7 R5 45 70 600 Bussmann JJS-70 T
-0060-7 R5 51 80 600 Bussmann JJS-80 T
-0070-7 R6 70 100 600 Bussmann JJS-100 T
-0100-7 R6 82 125 600 Bussmann JJS-125 T
-0120-7 R6 103 150 600 Bussmann JJS-150 T
-0145-7 R6 121 200 600 Bussmann JJS-200 T
-0175-7 R6 150 200 600 Bussmann JJS-200 T
-0205-7 R6 188 250 600 Bussmann JJS-250 T
PDM code: 00096931-J
Copper cables with concentric copper shield
Max. load current
A
Cable type
AWG/kcmil
18 14
22 12
31 10
44 8
57 6
75 4
88 3
101 2
114 1
132 1/0
154 2/0
176 3/0
202 4/0
224 250 MCM or 2 x 1
251 300 MCM or 2 x 1/0
PDM code: 00096931
ACS800-U4
type
Frame size Input
current
Fuse
A A V Manufacturer Type UL class
