Technical data
103
NEMA data
Ratings
The NEMA ratings for the ACS800-U4 with 60 Hz supplies are given below. The
symbols are described below the table. For sizing, derating and 50 Hz supplies, see
section IEC data.
ACS800-U4 size I
max
Normal use Heavy-duty use Frame
size
Air flow Heat
dissipation
A
I
2N
A
P
N
HP
I
2hd
A
P
hd
HP ft
3
/min BTU/Hr
Three-phase supply voltage 208 V, 220 V, 230 V or 240 V
-0002-2 8.2 6.6 1.5 4.6 1 R2 21 350
-0003-2 10.8 8.1 2 6.6 1.5 R2 21 350
-0004-2 13.8 11 3 7.5 2 R2 21 410
-0006-2 24 21 5 13 3 R3 41 550
-0009-2 32 27 7.5 17 5 R3 41 680
-0011-2 46 34 10 25 7.5 R3 41 850
-0016-2 6242153110 R461 1150
-0020-2 72 54 20 * 42 15 ** R4 61 1490
-0025-2 86 69 25 54 20 ** R5 147 1790
-0030-2 112 80 30 68 25 ** R5 147 2090
-0040-2 138 104 40 * 80 30 ** R5 147 2770
-0050-2 164 132 50 104 40 R6 238 3370
-0060-2 202 157 60 130 50 ** R6 238 4050
-0070-2 282 192 75 154 60 ** R6 238 4910
Three-phase supply voltage 380 V, 400 V, 415 V, 440 V, 460 V or 480 V
-0004-5 6.5 4.9 3 3.4 2 R2 21 410
-0005-5 8.2 6.2 3 4.2 2 R2 21 480
-0006-5 10.8 8.1 5 5.6 3 R2 21 550
-0009-5 13.8 11 7.5 8.1 5 R2 21 690
-0011-5 17.6 14 10 11 7.5 R2 21 860
-0016-5 2421151510 R341 1150
-0020-5 3227202115 R341 1490
-0025-5 4634252720 R341 1790
-0030-5 6242303425 R461 2090
-0045-5 7254403930 R461 2770
-0050-5 86 65 50 52 40 R5 147 3370
-0060-5 112 79 60 65 50 R5 147 4050
-0070-5 138 96 75 77 60 R5 147 4910
-0105-5 170 141 100 100 75 R5 238 7340
-0100-5 164 124 100 96 75 R6 238 6610
-0120-5 202 157 125 124 100 R6 238 7890
-0140-5 282 180 150 156 125 R6 238 9600
-0205-5 326 254 200 215 150 R6 238 12980
