Planning the cabinet assembly
34
360° high frequency grounding of the control cable shields is recommended at their
entries. The shields can be grounded by means of conductive shielding cushions
pressed against the cable shield from both directions:
Shielding cushion
(conductive)
Cable
Cable grommet
Bare cable shield
Cabinet bottom plate
