AC 80 User’s Manual 4-27
Essential Settings Only the user-adjustable settings are represented. (The tables also
include the information readable from the output terminals.) For more
details, see the AC 80 PC Elements Reference Manual.
MVICHAN
Base part:
MVINODE
MVB
NAME Max. 20 characters
ACT 0 = Spare element
1 = Active element
NET Network number of MVI channel.
NODE Individual node number of MVI channel.
MASTER MVI channel in slave (0) or master (1) mode.
TIMESYNC Time synchronisation:
NONE; MASTER; SLAVE
NAME Max. 20 characters
ACT 0 = Spare element
1 = Active element
NET MVI network number.
REMNODE Remote node number.
In Master mode: node number of Slave
In Slave mode: node number of Master
NAME Max. 12 characters
ACT 0 = Spare element
1 = Active element
REGADDR Register start address in external PLC/RTU.
In RCOM: MVB identifier.
CMDCODE Command code to be executed by the MVI protocol
handler (protocol-dependent).
AUXINFO1 Auxiliary information 1 (protocol-dependent).
AUXINFO2 Auxiliary information 2 (protocol-dependent).
NO_BREC Number of Boolean records DAT(B).
NO_INT Number of integer records DAT(I).
NO_INTL Number of long integer records DAT(IL).
NO_REAL Number of real records DAT(R).
SOURCE Source. Defines the direction of the data transmission
(RECEIVE; SEND).
