ABB Advant Controller 80 - Power Supply Connection Details

Chapter 2 – AC 80 Hardware and Connections
AC 80 User’s Manual 2-7
Power Supply
Connection
The AC 80 is powered by a single or redundant 24 V d.c. (19.2 to 30 V)
supply. The table below gives the current consumption at three different
voltages (without I/O modules).
Power Supply Terminals The power supply terminals accept wire sizes from 0.2 to 2.5 mm
2
(24 to 14 AWG). The terminal designations are as follows:
Note: It is recommended that the AC 80 and the I/O devices be
powered from separate supplies.
Voltage [V d.c.]
Current [mA]
Typical Maximum
19.2 310 520
24 250 415
30 200 330
X1B Designation Description
1L+ +24 V (in)
2 L+ +24 V (out)
3 SA Redundant power supply monitor input
X1A Designation Description
1 L– 0 V (in)
2L– +0 V (out)
3 SA Redundant power supply monitor input
