ABB Advant Controller 80 User Manual

AC 80 User’s Manual 4-19
S800 Analogue Input
Modules
The DB elements for controlling analogue inputs are shown in the table
below.
S800 Analogue Output
Modules
The DB elements for controlling analogue outputs are shown in the
table below.
S800 Digital Input
Modules
The DB elements for controlling digital inputs are shown in the table
below.
S800 Digital Output
Modules
The DB elements for controlling digital outputs are shown in the table
below.
AI Module DB Element Channels Type
AI810 AI810 8 0 to 20 mA, 0 to 10 V
AI820 AI820 4 ± 20 mA, ± 10 V, ± 5 V
AI830RTD AI830 8 for PT100, Cu10, Ni100, Ni120
AI835 AI835 8 for Thermocoupling, mV
AO Module DB Element Channels Type
AO810 AO810 8 0 to 20 mA, 0 to 10 V
AO820 AO820 4 ± 20 mA, ± 10 V, ± 5 V
DI Module DB Element Channels Type
DI810 DI810 16 24 V d.c.
DI820 DI820 8 120 V a.c.
DI821 DI821 8 230 V a.c.
DO Module DB Element Channels Type
DO810 DO810 16 24 V d.c.
DO820 DO820 8 230 V (relay)

ABB Advant Controller 80 Specifications

General

Brand	ABB
Model	Advant Controller 80
Category	Controller
Language	English
