Chapter 2 – AC 80 Hardware and Connections
2-10 AC 80 User’s Manual
Power-up Procedure
1. Measure that the voltages are correct on the power switch unit.
2. Switch on the circuit breakers on the power switch.
3. The AC 80 indicates the power-on status with the following LEDs:
Function
LED
Colour
LED
Designation
Operating OK Green R
Power OK Green P
Battery OK Green B
AF 100 Active Yellow
(flashing)
T1 and T2
States P1 to P6 Yellow see page 2-4
Fault/Alarm, I/O Modules/PM820-2 Red F
