ControlMaster CM30 and CM50
Universal process controllers,
1
/4 and
1
/2 DIN 3 Display Overview
IM/CM/ED–EN Rev. B 5
3 Display Overview
The ControlMaster display and icons are shown in Fig. 3.1:
Fig. 3.1 ControlMaster CM30 and CM50 Displays and Icons
CM50
1000.0
0.0
479.2
500.0
74.9
AUTO
LOCAL
PSI
PV
SP
OP
ControlMaster
CM30
PSI
PV
SP
OP
ControlMaster
479.2
500.0
74.9 %
PV Value
Bargraph
Setpoint Value
Icons
Access 
Level
Manual 
Mode
Local 
Setpoint
Remote
Setpoint
Output Value
Auto 
Mode
Operator
Level
Menu
Icons
Process
Alarm
Autotune
Feedforward
Totalizer
Running
Adjust–
Indicates which
value is adjusted
by the
/
keys
Totalizer
Stopped
Adaptive
Gain

ABB CM30 Specifications

General

Product Name	CM30
Product Type	Controller
Manufacturer	ABB
Frequency	50 / 60 Hz
Protection Class	IP20
Mounting	DIN Rail
Operating Temperature	-25°C to +60°C
