ABB COMMANDER 300 - Alarm and Relay Configuration; General Parameters (AlarmsRelays)

16
…8 COMMUNICATION
…8.6.1 General Parameters
Parameter Mnemonic
Command
Reply Interpretation
Read
(R)
Write
(W)
Display Parameters
Display Full Scale
DS Yes Yes –9999 to +9999
Display Decimal Point
Position
DP Yes Yes 0 to 3 positions
Display Zero
DZ Yes Yes –9999 to +9999
Display Units UM Yes Yes 0 = None
1 = DEG C
2 = DEG F
Bar Graph %/Bar
Value
GI Yes Yes 1 to 10(%)
Analogue Output Parameters
Analogue Output Full
Scale
AS Yes Yes 0.0 to 20.0mA
Analogue Output
Zero
AZ Yes Yes 0.0 to 20.0mA
Set Up Alarms Parameters
Relay 1 Action R1 Yes Yes 0 Negative
1 Positive
Relay 2 Action R2 Yes Yes As for Relay 1 Action
Relay 3 Action R3 Yes Yes As for Relay 1 Action
Relay 4 Action R4 Yes Yes As for Relay 1 Action
Process Alarm Type
Alarm A
Alarm B
Alarm C
Alarm D
Alarm E
Alarm F
Alarm G
Alarm H
Alarm J
Alarm K
YA
YB
YC
YD
YE
YF
YG
YH
YJ
YK
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
0 = None
1 = High process
2 = Low process
3 = High deviation
4 = Low deviation
5 = High output
6 = Low output
7 = Fast rate
8 = Slow rate
9 = Mode alarm
Process Alarm
Trip Levels
Alarm A
Alarm B
Alarm C
Alarm D
Alarm E
Alarm F
Alarm G
Alarm H
Alarm J
Alarm K
LA
LB
LC
LD
LE
LF
LG
LH
LJ
LK
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
0 = None
1 = High process – Display range
2 = Low process – Display range
3 = High deviation – ±Display range
4 = Low deviation – ±Display range
5 = High output – 0.0 to 100.0%
6 = Low output – 0.0 to 100.0%
7 = Fast rate – 0.5 to 500.0
8 = Slow rate – 0.5 to 500.0
9 = Mode alarm:
0 = Auto
1 = Manual
2 = Local set point
3 = Remote set point
4 = Process variable failure
5 = Remote set point failure
6 = Position feedback failure
7 = Any input failure
