8 COMMUNICATION…
8.6.4 Multiple Read Parameters…
Parameter Group Mnemonic Parameters
General Parameters
MG
Measured Value
Instrument Status
Control set Point
Control Output
Control Parameters
CP Proportional Band
Integral Action Time
Derivative Action Time
Approach Band
Cycle Time
Hysteresis Value
Channel 1 (Process Variable) Input
Parameters
C1 Input Type
Lineariser Type
Lineariser Units
Lineariser Full Scale
Lineariser Zero
Range Full Scale
Range Zero
Broken Sensor Drive
Fault Detect Level
Default Action
Default Output
Filter Time Constant
Channel 2 (Remote Set Point) Input
Parameters
C2 Input Type
Lineariser Type
Lineariser Units
Lineariser Full Scale
Lineariser Zero
Range Full Scale
Range Zero
Broken Sensor Drive
Fault Detect Level
Default Action
Default Output
Channel 3 (Position Feedback) Input
Parameters
C3 Input Type
Range Full Scale
Range Zero
Fault Detect Level
Default Action
Alarm Status
AS Alarm A
Alarm B
Alarm C
Alarm D
Alarm E
Alarm F
Alarm G
Alarm H
Alarm J
Alarm K
Alarm Parameters
AA
to
AK
Alarm Type
Alarm Trip Level
Alarm Hysteresis Value
Alarm Status
