ABB COMMANDER 300 - Control and Feedback Parameters; General Parameters (ControlFeedback)

17
8 COMMUNICATION…
8.6.1 General Parameters…
Parameter Mnemonic
Command
Reply Interpretation
Read
(R)
Write
(W)
Set Up Alarms Parameters (continued)
Process Alarms
Hysteresis Value
Alarm A
Alarm B
Alarm C
:
:
Alarm H
Alarm J
Alarm K
HA
HB
HC
:
:
HH
HJ
HK
Yes
Yes
Yes
:
:
Yes
Yes
Yes
Yes
Yes
Yes
:
:
Yes
Yes
Yes
0.0 to 100.0%
or
Engineering Units
(within the display span),
depending on the Alarm Type
Process Alarms Status
Alarm A
Alarm B
Alarm C
:
:
Alarm H
Alarm J
Alarm K
JA
JB
JC
:
:
JH
JJ
JK
Yes
Yes
Yes
:
:
Yes
Yes
Yes
No
No
No
:
:
No
No
No
0 = Inactive/Acknowledged
1 = Active/Acknowledged
254 = Active/Unacknowledged
255 = Inactive/Unacknowledged
Process Alarms
Acknowledged State
Alarm A
Alarm B
Alarm C
:
:
Alarm H
Alarm J
Alarm K
KA
KB
KC
:
:
KH
KJ
KK
Yes
Yes
Yes
:
:
Yes
Yes
Yes
Yes
Yes
Yes
:
:
Yes
Yes
Yes
0 = Acknowledged
1 = Unacknowledged
Alarm Acknowledge Enable
EK Yes Yes 0 = None
1 = Normal
2 = Latch
Relay 1 State L1 Yes No 0 = Off
1 = On
Relay 2 State L2 Yes No As for Relay 1 State
Relay 3 State L3 Yes No As for Relay 1 State
Relay 4 State L4 Yes No As for Relay 1 State
Relay 1 Logic Equation Q1 Yes Yes See Section 8.1.2 on page 6
Relay 2 Logic Equation
Q2 Yes Yes See Section 8.1.2 on page 6
Relay 3 Logic Equation
Q3 Yes Yes See Section 8.1.2 on page 6
Relay 4 Logic Equation
Q4 Yes Yes See Section 8.1.2 on page 6
Relay 1 Logic Equation Syntax
Y1 Yes No 0 = No Error (in equation 1)
Relay 2 Logic Equation Syntax Y2 Yes No 0 = No Error (in equation 2)
Relay 3 Logic Equation Syntax Y3 Yes No 0 = No Error (in equation 3)
Relay 4 Logic Equation Syntax Y4 Yes No 0 = No Error (in equation 4)
Rate Alarm Filter RA Yes Yes 0 to 60 seconds
