ABB COMMANDER 300 - Profile Parameters

18
…8 COMMUNICATION
…8.6.1 General Parameters
Parameter Mnemonic
Command
Reply Interpretation
Read
(R)
Write
(W)
Set Up Control Parameters
Power Fail Mode FM Yes Yes 0 = Last
1 = Manual
2 = Auto
Power Fail Output
Auto-Manual
FO Yes Yes 0 to 100.0%
Power Fail Output
Manual-Manual
FP Yes Yes 0 to 100.0% (–0.1 = last manual output)
Power Fail Indication
Enable
PI Yes Yes 0 = No
1 = Yes
Power Fail Message PM Yes Yes 0 = No
1 = Yes
Auto/Manual Switch
Enable
ME Yes Yes 0 = No
1 = Yes
Control Output
High Limit
OH Yes Yes 0 = Off
1 = On
Control Output
Low Limit
OL Yes Yes 0 to 100.0%
Control Action CA Yes Yes 0 to 100.0%
Logic Input 1 Type N1 Yes Yes
0 = None
1 = Auto/Manual
2 = Local/Remote
3 = Acknowledge
4 = Fixed Set Point
5 = Profile Start
6 = Profile Reset
7 = Profile Skip
Logic Input 2 Type N2 Yes Yes
Logic Input 3 Type N3 Yes Yes
Logic Input 4 Type N4 Yes Yes
Logic Input 1 State F1 Yes No 0 = Open (5V)
1 = Closed (0V)
Logic Input 2 State F2 Yes No 0 = Open (5V)
1 = Closed (0V)
Logic Input 3 State F3 Yes No 0 = Open (5V)
1 = Closed (0V)
Logic Input 4 State F4 Yes No 0 = Open (5V)
1 = Closed (0V)
Configured O/P
Value
CV Yes Yes 0.0 to 100.0 (–0.1 = LAST)
Fixed Set Point 1 1F Yes Yes Engineering units
Fixed Set Point 2 2F Yes Yes Engineering units
Position Feedback Parameters
Ratio Value Y1 Yes Yes 0.10 to 9.99
Bias Value Y2 Yes Yes –100 to +100
Deadband Value RA Yes Yes 0.0 to 20.0(%)
